CP-UNP-D2521L10-DP 2 MP Full HD Network IR PTZ Camera– 100 Mtr.
- 1/2.8” 2MP CMOS Image sensor (0.9071 centimeters)
- Max. 25/30fps@1080P
- Powerful 25x Optical and 16x Digital zoom
- WDR(120dB), 3D-DNR, Day/Night (ICR), ROI, Defog, AWB, BLC, HLC
- Support Starlight Function
- Mobile Software: iCMOB, gCMOB
- CMS Software: KVMS Pro
Product Full Description
This Series has been developed mainly to present the PTZ cameras that have been designed to submerge into the surface and keep a secret eye on the scene. The Lite Series obeys the notion of stealth surveillance, while at the same time, expanding the image quality through using the wide dynamic range technology, which provides a balanced lighting and clears distortions.
Specification
| Image Sensor | 1/2.8” 2MP PS CMOS (0.9071 centimeters) |
| Effective Pixels | 1920(H) x 1080(V), 2 Megapixels |
| Resolution | 2MP |
| S/N Ratio | More than 50dB |
| Minimum Illumination | Color: 0.005Lux@F1.6; B/W: 0.0005Lux@F1.6; 0Lux@F1.6 (IR on) |
| Focal Length | 4.8mm~120mm |
| White Balance | Auto, ATW, Indoor, Outdoor, Manual |
| Max Aperture | F1.6 ~ F4.4 |
| Focus Control | Auto / Manual |
| Close Focus Distance | 100mm~ 1000mm |
| Angle of View | H: 62.8° ~ 2.6° |
| Iris | Auto/Manual |
| DORI Distance | 1613m(Detect) 646m (Observe) 323m (Recognize) 161m (Identify) |
| AGC Control | Auto / Manual |
| Back Light Compensation | BLC / HLC / WDR(120dB) |
| ROI | Support |
| Motion Detection | Support |
| Optical Zoom | 25X |
| Shutter Speed | 1/1s~1/30,000s |
| Digital Zoom | 16x |
| Pan Travel | 0°~360° endless, Pan Speed: 0.1° ~ 200°/sec |
| Tilt Travel | -15° ~ 90° auto flip 180°, Tilt Speed: 0.1° ~120°/sec |
| Manual Speed | Pan: 0.1° ~200° /s; Tilt: 0.1° ~120° /s |
| Presets | 300 |
| Preset Speed | Pan: 240° /s; Tilt: 200° /s |
| Power up Action | Auto restore to previous PTZ and lens status after power failure |
| Idle Motion | Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period |
| Day/Night: IR Cut Filter | Auto(ICR) / Color / B/W |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Event Trigger | Motion detection, Video tampering, Network disconnection, IP address conflict, Illegal access, Storage anomaly |
| Video Streaming | Main stream: 1080P/720P(1 ~ 25/30fps) Sub stream1: D1/CIF(1 ~ 25/30fps) Sub stream2: 720P/D1/CIF(1 ~ 25/30fps) |
| Audio Compression | G.711a/G.711Mu/G.726/AAC |
| Special Features | IR Range upto 100m, Defog, Up to 300 Presets, 5 Pattern, 8 Tour, Auto Pan , Auto Scan |
| Audio Streaming | 1/1 channel In/Out |
| Smart Detection | Tripwire, Intrusion, Abandoned/Missing, Face Detection |
| Networking | RJ-45 (10/100Base-T) |
| IVS | Tripwire, Intrusion,Abandoned/Missing, Face Detection |
| Protocols | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x, ONVIF Profile S&G, API |
| Alarm | 2/1 channel In/Out |
| IR Range | 100 Mtr. |
| Operating Temperature | -40ºC ~ 70ºC / Less than 95% RH |
| Smart Phone | iPhone, iPad, Android Phone |
| Memory Slot | Micro SD card 256GB |
| Weatherproof Standard | IP66 |
| Dimension | Φ160(mm) x 295(mm) |
| Power Source | DC 12V/3A, PoE+ (802.3at) |
| Power Consumption | 13W, 22W (IR on) |
| Casing | Metal |
| Weight | 3kg |
